The JUG Stall Waterer was designed with your horse in mind. The durable rotomolded plastic construction features rounded edges for animal safety and a stainless steel bite plate to prevent damage from cribbing.

The same clean, freshwater technology of the JUG ground-mounted, stand-alone models is offered in the Stall units. The waterer has a 2-gallon reservoir capacity for your animals and a quick recovery float valve.

TIP: There is a slight mark on each bowl that shows the suggested level of water to have in each unit.

The Stall Waterer has an external drain plug and a float adjustment screw to aid in ease of maintenance, cleaning, and water level management.

The Stall Waterer features a versatile installation allowing you to run the waterline from below or overhead. The overhead application will require a small drill to drill a small access hole into the back corner of the unit and plumb in your water from the top.

FEATURES

• Animals adapt easily - no flaps to lift, discs or balls to push. Animals drink naturally, even young ones
• Clean, Clean water - The Draw Tube/ Feed Trap doesn't allow debris to fall into the tank reservoir, which means less maintenance, and clean water.
• Super Insulation - The strong polyethylene body has thick urethane foam which means cooler water in the summer and warmer water in the winter.
• External Adjustment Screw - Provides easy adjustment of the water level in the bowl when introducing new animals to their water source. After they learn there is a constant clean water supply, lower the water level. It’s easy for you and your animals.
• Mounting - The 303 FB JUG is mounted against a flat wall of a stall. Use your own hardware or purchase the Wall Mounting Kit #13550 separately.
• External Drain Plug - For easy draining of water from the JUG’s 2-gallon reservoir.
• Bite Guard - An 18 gauge stainless steel guard, prevents damage from cribbing. Capacity: The 303 JUG with its 2-gallon reservoir, and quick recovery Float Valve, offers plenty of water capacity for your horses, large or small.
• Valve - The Fluidmaster Float Valve used on the 303 is among the most reliable, trouble-free valves available today.
• Energy Efficient- If you have a cold barn, you can count on the super insulation in the 303 WH (With Heat) to conserve heat loss. A low 30-watt heater that is thermostatically controlled gives you the added assurance of frost-free water. 303 energy usage is minimal.


INSTALLATION

Water and electric lines run underground below the frost line, then up into the fountain through the Riser Tube. The 303 Riser Tube protects the water supply line from the cold by insulating it in urethane foam, and warming it with a low wattage heating element.

Modern, Yet Simple The 303 JUG features the most modern up-to-date styling available in a horse stall waterer. Yet the 303 is extremely simple with very few moving parts

303 Riser Tube Construction

Rugged 1/4” PVC Schedule 80 case. Available in 3FT, 4FT, 5Ft, 6Ft and 7Ft lengths, as well as 2Ft extensions. Super insulation provides protection against freeze-ups, lowers energy costs in the winter, and provides cooler water in the summer.
