Jobe Topaz Valve Short Tail 1" Inlet TPV0100D

Jobe Topez 1" Inlet Trough Valves are float-operated valves for use in the automatic filling of water troughs, tanks, cisterns, etc. The valve is configured for above or below water mounting. The float operates a small pilot valve which in turn operates the main diaphragm valve. Topaz trough valves are a good choice where their high flow, compact, robust, non-corrosive construction, and high level of adaptability are needed.

Short Tail is ideal for top applications. Comes with a standard 125MM Float (4.92" float).

APPLICATIONS

Maintaining Water Levels in:

• Animal Drinking Troughs
• Water Storage Tanks
• Water Cisterns
• Air Conditioning Systems
• High-Pressure Cleaning Systems
• Irrigation Applications

TIP: WHEN INSTALLING - be sure to flush the waterline before installing the valve to prevent debris from accumulating in the valve.

FEATURES

• Short Tail valves are ideal for Top Mount app.ications
• Valve body screws apart by hand for easy servicing
• Flow stops when unscrewed for servicing
• Built-in check valve
• Fully adjustable float angle
• Pressure range 5-100 PSI
• Non-corrosive material construction
• Has switch to lock the valve in the off position
